CYT1000AT single segment LED linear constant current control chip
CYT1000AT is a linear constant current IC with adjustable output current, high constant current precision, simple application scheme, few peripheral components in the system structure, over-temperatur...
Model:
Product Description:
CYT1000AT is a linear constant current IC with adjustable output current, high constant current precision, simple application scheme, few peripheral components in the system structure, over-temperature protection function, more safety and reliability.
The output current is adjustable from 5 mA to 60 mA
Constant current accuracy 3%
Maximum withstand voltage 700V
With over-temperature protection function
No EMI problem
Chip and LED share aluminum substrate with simple circuit and high cost performance.
Package: ESOP8
